Arduino Mini USB Nano V3.0 ATmega328 5V 16M Nano I / O bővítő szenzor

Arduino Mini USB Nano V3.0 ATmega328 5V 16M Nano I / O Expansion sensor ShieldSpecification:100% BRAND NEW!
100% New,Arduino-Compatible Board
Fully Compatible to Arduino Nano V3.0 ATmega328P-AU
ATmega328 Microcontroller
Bootloader installed, ready to upload sketches from Arduino software
Microcontroller ATmega328P-AU
Operating Voltage 5V
Input Voltage (recommended) 7V-12V
Input Voltage (limits) 6V-20V
Digital I/O Pins 14 (of which 6 provide PWM output)
Analog Input Pins 8
DC Current per I/O Pin 40 mA
DC Current for 3.3V Pin 50 mA
Flash Memory 32 KB (ATmega328) of which 2 KB used by bootloader
SRAM 2 KB
EEPROM 1 KB
Clock Speed 16 MHz
Size（Long）45mm *（wide1）18 mm *（high）20mm
Nano shield:
Compatible with Arduino or Arduino-compatible Nano v3.0
14 I/O Pin (servo type with GND, power and signal)
8 analog Pin with power output and GND
6 PWM Pin
1 Servo power input
5 I2C expansion Pin
AREF output
3.3V output Shipping Included:1PCS * Arduino Nano V3.0
3PCS * Free Pin
1PCS * Arduino Nano V3.0 shield.
