ÚJ VS1053B MP3 Zenei árnyékolópanel Modul TF kártyanyílással Arduino UNO R3-hoz

NEW VS1053B MP3 Music shield board Module with TF card slot For Arduino UNO R3
Features:Can play a variety of music formats, support for OGG encoding real-time recording
SPI interface, the control signal lines are led out
A headphone and stereo output
A microphone for recording
A line_in input interface
Power indicator
3.3V and 2.8V of LDO chip AMS-1117 on board, provides up to 800mA current
A single power supply: 5 VDC
12.288 Mhz crystal
TF card slot
Decodes formats:Ogg Vorbis
MP3 = MPEG 1 & 2 audio layer III (CBR VBR ABR)
MP1 & MP2 = MPEG 1 & 2 audio layers I & II optional
MPEG4 / 2 AAC-LC( PNS), HE-AAC v2 (Level 3) (SBR PS)
WMA4.0/4.1/7/8/9 all profiles (5-384 kbps)
FLAC lossless audio with software plugin (upto 24 bits, 48 kHz)
WAV (PCM IMA ADPCM)
General MIDI 1 / SP-MIDI format 0
Package include:
1 x MP3 Music VS1053B shield board with TF card slot work with Arduino UNO
