GY-BME280-3.3 BME280 3.3V légköri nyomásérzékelő modul Arduino SPI IIC

GY-BME280-3.3 BME280 3.3V Atmospheric Pressure Sensor Module for Arduino SPI IIC
GY-BME280-3.3 BME280 Atmospheric Pressure Sensor Module for Arduino SPI IIC


100% brand new and high quality!ME-BME280 is a Breakout Board featuring a Sensortec ME280 Temperature, Humidity & Pressure Sensor.The board has selectable I2C address jumper (solder link GS2), I2C pull-up resistors, 7 pin header 2.54mm, and two mounting holes 3.5mm.Default setting of the board; single power rail Vdd=Vdd_IO (solder link GS1), pull-ups resistors (R2, R3) 10k, protocol selector resistor 0ohm (R1), decoupling capacitors 0.1uF on both power supply pins Vdd & Vdd_IO.If you connect board to both power rails VDD_IO 1.8V and VDD 3.3V be sure to remove the power rail jumper GS1!BME280 FeaturesPackage 2.5 mm x 2.5 mm x 0.93 mm metal lid LGADigital interface I2C (up to 3.4 MHz) and SPI (3 and 4 wire, up to 10 MHz)Supply voltage VDD main supply voltage range: 1.71 V to 3.6 VVDDIO interface voltage range: 1.2 V to 3.6 VCurrent consumption 1.8 uA @ 1 Hz humidity and temperature2.8 uA @ 1 Hz pressure and temperature3.6 uA @ 1 Hz humidity, pressure and temperature0.1 uA in sleep modeOperating range -40… 85 C, 0…100 % rel. humidity, 300…1100 hPa- Humidity sensor and pressure sensor can be independently enabled/disabled
Package Included:1PCS I2C/SPI Breakout Temperature Humidity Barometric Pressure BME280 Digital Sensor
Note:The supply voltage range of this item is 1.71 V to 3.6 V,if you need 1.8 - 5V DC,Pls see as below
201709070605 - ali110 (281)
