DC egyenáramú átalakító állandó áramforrás 250W 10A fokozatos növelés LED-meghajtó

DC DC Converter Constant Current Power supply 250W 10A Step up Boost LED Driver
DC DC boost converter Constant Current Mobile Power supply 10A 250W LED DriverDescriptions:Module name :250W boost constant current moduleModule properties: non-isolated step-up module (BOOST)Input voltage: DC8.5V-48VInput current: 10A (MAX) exceeds 8A please enhance heat dissipationQuiescent current: 10mA (12V liter 20V, the output voltage, the higher
the current will increase too quiet)Output voltage: 10-50V continuously adjustableConstant] range: 0.2-8ATemperature: -40 to 85 degrees (ambient temperature is too high, please enhance heat dissipation)Operating frequency: 150KHzConversion efficiency: up to 96% Overcurrent protection: ThereInput reverse polarity protection: Yes,Installation: 4 3mm screw holesConnection method: Connection OutputModule size: Length 70mm width 36mm height 13mmSingle module: 50 gApplications:1, DIY a power supply, 12V can input and output can 12-50V adjustable.2, the power supply for your electronic device, according to your
system can set the output voltage value.3, as the car power supply for your laptop, PDA or a variety of digital
products supply.4, DIY a mobile notebook power supply: 12V coupled with high-capacity
lithium battery pack, so you can go where light where books.5, solar panel regulator.6, to the battery, rechargeable lithium batteries.7, driving high-power LEDlights.Package Included:1 x DC DC boost converter Constant Current Mobile Power supply 10A 250W LED Driver
