USR-ES1 ENC28J60 W5500 lapkakészlet SPI a LAN / Ethernet átalakító TCP / IP modul

USR-ES1 ENC28J60 W5500 Chip SPI to LAN/ Ethernet Converter TCP/IP Module
DescriptionHigh speed SPI interface 80MHz
Hardware-TCPIP-protocol stack user built in, almost without understanding the complex network protocol knowledge
Supports up to 8 Socket
Support TCP, UDP, ICMP, IPv4, ARP, IGMP, PPPoE protocol
Integration of the data link layer, physical layer
Support the wakeup
Support high speed serial peripheral interface (SPI model 0, 3)
Internal 32K bytes receive buffer
The embedded 10BaseT/100BaseTX Ethernet physical layer (PHY)
Support auto negotiation (10/100-Based full duplex or half duplex)
Does not support the IP patch
The working voltage of 3.3V, I/O and 5V voltage signal
LED display (full duplex or half duplex, network connection, network speed,active)
Pin type package ultra small, convenient for embedded applications
Application of C sample projectProduct CharactersPower supply mode:3.3V external power supply, current should be more than 200mA;
Control interface:The TTL level, 3.3V SPI interface;
PCB size:23 * 25 mm;
Mechanical Dimensions:28.5 * 23 * 24;Package1 X USR-ES1 ENC28J60 W5500 Chip SPI to LAN/ Ethernet Converter TCP/IP Module
